Full automatic Autoclaved Aerated Concrete Production Line for AAC block Plant

Name: Full automatic Autoclaved Aerated Concrete Production Line for AAC block Plant
Brand: HUILONG
Rating: 5.0 (40 reviews)

Our AAC production line is simpler and quicker than traditional methods. There are patents of Germany and Sweden and Japan included in the production equipments.

Availability:

Quantity:



Inquire Add to Basket

Model:
AAC LINE
Brand:
HUILONG

Product Description

Basic Info

AAC (Autoclaved aerated concrete) block Main raw materials of AAC are siliceous material (sand, fly ash and Silicon tailings) and Calcium materials (lime and cement) mixed with foaming agent (aluminum powder). It is the product of light porous silicate through the following processes: batching, mixing, pouring, hardening, cutting, autoclaving and curing etc. Because of large amount of well-distributed tiny pores after foaming, it is named autoclaved aerated concrete.

Based on the shape of AAC products, it can be divided into: AAC blocks and AAC panels. It is a revolutionary material offering an unique combination of high durability and strength, low weight, excellent heat insulation, fire resistant, noise absorption, unprecedented build ability and superior ecological green features.

Production Process

HUILONG supply full set of AAC production line, including plant design, automation design and all machines such as cutting machine, milling ball, mould, autoclaves, turnover machine, etc. The automatic production line can make AAC Panels and AAC Blocks with production capacity from 100,000CBM to 60,000CBM per year.

The AAC production line is simpler and quicker than traditional methods. There are patents of Germany and Sweden and Japan included in the production equipments.

Size

ITEM	AAC-5	AAC-10	AAC-15	AAC-20	AAC-30
Capacity m3/year	50000	100000	150000	200000	300000
Cake Size m3	4.2x1.2x0.6	4.2x1.2x0.6	4.2x1.2x0.6	4.8x1.2x0.6	4.8x1.2x0.6
Installation Power, kw	300	600	600	900	1200
Production Cycle, mould/min	5	6	6	6	6
Workshop Area,m2	3000	3000	3500	4000	5000
Plant Area,m3	20000	20000	25000	30000	35000
